Hydraulic
Platform Lift
Heavy-duty hydraulic wheelchair lift for vans and buses. Robust platform design with 300kg loading capacity and integrated safety rails for reliable daily operation.
Key Features
The Hydraulic Platform Lift delivers robust, heavy-duty lifting performance with integrated safety systems for dependable daily wheelchair access.
350kg Heavy-Duty Capacity
Solid platform with mechanical automatic roll stops supports wheelchairs up to 350kg.
Hydraulic Drive System
Powerful hydraulic system ensures smooth, stable and fully automatic lifting, lowering and folding.
Integrated Safety Rails
Handrails and anti-skid platform provide comfort and security, with warning sound during operation.
Manual Backup
Self-locking device and manual backup function for emergency, plus optional mobile phone control.
Technical Specifications
Detailed technical parameters for the Hydraulic Platform Lift system.
| Voltage | 12V DC or 24V DC |
| Power | 500W |
| Loading Capacity | 350 kg |
| Max Lifting Height | 1200 mm |
| Platform Net Width | 720 mm |
| Platform Net Length | 1140 mm |
| Overall Height | 1335 mm |
| Control | Wired Remote + Mobile Phone (optional) |
| Certification | CE, E-Mark, ISO 9001 |
Compatible Vehicles
Designed for vans, minibuses, and commercial vehicles. Custom installation kits available for specific models.
Frequently Asked Questions
Capacity, dimensions, safety and fit answers for the Hydraulic Platform Lift.
What is the Hydraulic Platform Lift?
It is a heavy-duty hydraulic wheelchair lift for vans, minibuses and commercial vehicles. It lifts a wheelchair user up to 1200 mm to boarding height on a solid platform with automatic roll stops.
What are its capacity and dimensions?
Loading capacity is 350 kg. The platform measures 720 x 1140 mm and overall height is 1335 mm. Drive is hydraulic on 12V or 24V DC with a 500W motor.
What safety and control features does it offer?
Handrails, an anti-skid platform and mechanical automatic roll stops protect the passenger, and a warning sound sounds during operation. A self-locking device plus manual backup covers emergencies, and mobile-phone control is optional.
Which vehicles can use the Hydraulic Platform Lift?
It is designed for vans, minibuses and commercial vehicles with custom installation kits for specific models, and is CE, E-Mark and ISO 9001 certified.
